Intel 14nm Quad Core N3150 Dual Core i3 6006U i3 7100U CPU Mini PC with HDMI VGA Dual display 4K HD HTPC Fanless Micro Computer

Intel 14nm Quad Core N3150 Dual Core i3 6006U i3 7100U CPU Mini PC with HDMI VGA Dual display 4K HD HTPC Fanless Micro Computer
  • Продавецwww.arizonacardinalsvsdetroitlions.us
  • Список ценUS $121.18piece
  • Продажная ценаUS $121.18piece
  • ДоставкаБесплатная доставка
  • Рейтинги4,4 (448)

Oписание продукта

HTB15qaAMVXXXXXiXFXXq6xXFXXXMi5-4200uFanless Micro PC, Mini Nettop Computer

Intel Core i3 7100U/i5 7200U Dual Core, 3M Cache, TDP 15W,

DDR3 RAM, MSATA SSD ,WiFi, 4*USB 3.0, 1*VGA, 1*HDMI,
 Intel HD Graphics 620, [email protected] , Fanless, Metal Case
Core i7-7500U Kaby Lake CPU,  Dual Core,14nm Lithography,4M Cache,TDP 15W,
DDR4 RAM, WiFi, 4*USB 3.0, 1*DP, 1*HDMI,1*SD Card Port
 Intel HD Graphics 620, [email protected], Fanless,No Noise, Metal Case.


   01


Color:  i3 i5 Silver / i7 black
1-1g-

Kindly Remind:
1, This computer works with lower voltage at 1.35V instead of normal 1.5V RAM.
2, Warranty is 3 years for Barebone PC, 1 Year for RAM and Storage.
3, The RAM and SSD/HDD are from famous brand, the RAM is normally Samsung, Elpida, Hynix; The SSD is normally from Toshiba, Samsung, ADATA, Intel, Lite-on etc. they will be shipped out at random in stock.
4, The default Operating System Windows 10 Pro, it is just for testing, copied and activated but not licensed, please install the licensed one if you like it.
5, According to Aliexpress policy, it is buyer\'s duty to pay import tax; it is normally declared at USD105-120 to save buyer\'s tax, but not sure if it is free tax.
6, Please carefully read the SHOPPING GUIDELINES   on the bottom of this page. It is regarded as you have agreed all listed when you place an order. We won\'t take responsibility for any problems might caused except the quality problem of the product.
Thank you !

Window 10 Desktop:
HTB1AbhKLXXXXXXuXFXXq6xXFXXXi



HTB1bl4yHVXXXXcMXpXXq6xXFXXXO


Branded Spare Parts, Boyscott Fake Parts!!
Top Quality, 3 Year Warranty, Rest Assured!!
1,Quality Approval:
Certificate-2
2, Key Features:
CPU
1. Kaby Lake 14nm CPU Intel Core i3 7100U 2 cores 4 threads 2.4GHz 3MB cache TDP 15W HD Graphics 620.
2. Kaby Lake 14nm CPU Intel Core i5 7200U 2 cores 4 threads 2.5GHz up to 3.1GHz 3MB cache TDP 15W HD Graphics 620.
3. Kaby Lake 14nm CPU Intel Core i7 7500U 2 cores 4 threads 2.7GHz up to 3.5GHz 4MB cache TDP 15W HD Graphics 620.

RAM: Support DDR3L 1600MHz, max expanded to 16GB DDR3L-1600 SODIMM Notebook memory;

Storage: max expanded to 1*mSATA3 SSD and 1*2.5 inch laptop SSD/HDD SATA3, no limited on storage capacity;

Operating System: Default: Windows 10 Pro; Optional: Linux Ubuntu

Wireless: 300MB WiFi with 2 Antennas

I/O:
4*USB2.0, 4*USB3.0, 1*HDMI, 1*VGA, 1*LAN Gigabit (RJ45), 1*MIC, 1*SPK;
Internal ports: 1*mSATA3.0, support 6Gb/s, 1*SATA3.0, support 6Gb/s, 1*mini-PCIE port (for WIFI);

HD Out put: HDMI+VGA, support HDMI to DVI and HDMI to VGA

LAN port: 1*Gigabit RJ45 port speed up to 1Gbps;

Case Material: Brushed Aluminum Alloy;
04-7500U05-6500U07-7500U
04-7200U05-6200U07-7200U04-7100U07-6500U08060910241613

3, Product Specifications:
(Core i5 7200U and i3 7100U come with only silver case, support 1*HDMI and 1*VGA dual display)
Processor Intel® Core™ i3-7100U/i5-7200U Processor
Dual Core Quad Threads
Base Frequency 2.4GHz/Base Frequency 2.5GHz
14nm Lithography
Intel KABY LAKE SOC Chipset
3MB L3 Cache
15W TDP
Multimedia Instruction Set: 64-bit; MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, AVX
Processor Graphics Intel® HD Graphics 620
Graphics Base Frequency 300.00 MHz
Graphics Burst Frequency 1.00 GHz
Graphics Video Max Memory 32 GB
Max Resolution (HDMI 1.4): [email protected]
BIOS AMI BIOS, ACPI supported
RAM DDR3L-1600; 2gb/4gb/6gb/8gb/16gb optional, 2*DDR3 SO-DIMM SDRAM Slot
Storage SSD: 64GB/128GB/256GB/512GB available;  HDD: 500GB/1TB available
Operating System Default: Windows 10 Pro; Optional: Linux Ubuntu (Windows 7/8 not supported)
Audio Card ALC892 sound chip, 6-channel
Network Card RTL 8111E 10/100/1000 BaseT LAN
Wireless Wifi 802.11.b/g/n, 300M, Dual Antennas; Bluetooth 3.0 optional
I/O Port 1*HDMI, 1*VGA, 1*RJ45 LAN Port, 4*USB3.0, 4*USB2.0, 1*DC IN, 1*MIC, 1*SPK
SATA 1*mSATA3.0 Slot, 6Gb/s; 1*SATA3 Connector, 6Gb/s
MINI PCIE 1* MINI PCIE Slot for Wifi Module
Power In: DC100-240V AC/50-60Hz Out: DC 12V/3A
Operating Temperature 0°C~70°C (32°F~140°F)
Storage Temperature -20°C~80°C (-68°F~176°F)
Relative Humidity 10%~90% (non-condensing)
Size 205mmx 180mmx45mm
Package Content Mini PC, Power adapter, Power Cable, Wifi Antennas, Stand Bracket, Screws

(Core i7 7500U comes with only black case, support 1*HDMI and 1*DP(Max [email protected]) dual display)

Processor

Intel® Core™ i7 7500UProcessor

Dual Core Quad Threads



Base Frequency 2.7Ghz, Turbo Boost 3.5Ghz

14nmLithography

Intel KABY LAKESOC Chipset

4MB L3 Cache

15W TDP

Instruction Set 64-bit

Multimedia Instruction Set

MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, AVX

BIOS

AMI BIOS, ACPI supported

RAM

LPDDR3-1866, DDR3L-1600;

2gb/4gb/6gb/8gb/16gb optional, 2*SDRAM Slot

Storage

SSD: 32GB/64GB/128GB/256GB/512GB; HDD: 160GB/250GB/320GB/500GB/640GB/1TB

Operating System

Default: Windows 10 Pro; Optional:  Linux Ubuntu

Processor Graphics

Intel® HD Graphics 620

Graphics Base Frequency 300 MHz

Graphics Burst Frequency 1.05 GHz

Max Resolution (DP): [email protected]

Audio Card

ALC892 sound chip, 6-channel

Network Card

RTL 8111E 10/100/1000 BaseT LAN

Wireless

Wifi 802.11.b/g/n(150M or 300M), Dual Antennas; Bluetooth 4.0 optional

I/O Port

1*HDMI, 1*VGA, 1*RJ45 LAN Port, 4*USB3.0, 1*USB2.0, 1*SD Card Slot, 1*DC IN, 1*MIC, 1*SPK

SATA

1*MSATA3.0 Slot, 6Gb/s; 1*SATA3 Connector, 6Gb/s

MINI PCIE

1* MINI PCIE Slot for Wifi Module

Power

In: DC100-240V AC/50-60Hz Out: DC 12V/3A

Operating Temperature

0°C~70°C (32°F~140°F)

Storage Temperature

-20°C~80°C (-68°F~176°F)

Relative Humidity

10%~90% (non-condensing)

Size

220mmx 170mmx45mm

Weight

1.5~1.65kg

Package Content

Mini PC, Power adapter, Power Cable, Wifi Antennas, Stand Bracket, Screws

4, Product Advantages:

Small Size: All Kingdel Mini PC is smaller than A4 paper, some of them only 3.5 inch size, just like the HDD size used in traditional fat computers. Most of those small size mini pc can be mounted to the backside of monitor, and takes almost zero space on your desk, make your desk more clear and tidy.


Durability: all of the fanless mini pcs are highly intergrated, fanless design makes it silent in working and no need extra maintenance like normal fat comptuters. And most of their cases are made by aluminium alloy metal materia.

Low Power: all of the mini pcs work 12V power supply, power consumption is from 15W to 30W, compare to 150W traditional pc\'s consumption, it saves more than 80% energy.

Universal Performance: The mini pcs are compatiable to almost all popular operating systems, such as Windows, Linux. You can not only use it as personal computer at home, HTPC in living room, but also use it in office, training center, advertisement, factory, internet cafe and anywhere that needs computers to work.
Application
- used as HTPC(Home Theater Personal Computer). Connect HDTV with the HDMI cable, you can enjoy education online and play internet movies or games.
-used as Personal Computer, high configuration and fast speed, zero noise.
- Internet Bar. High speed Gigabit Ethernet and diskless certificate, support 3D games.
- Factory, classroom, bank, supermarket, manager rooms, stores.
- used in Library, reading room, hotel, training, call center, CCTV company.
1415
202122232526
5,Product photos
293031323334Attention:
Core i7 7500U comes with only black case, support 1*HDMI and 1*DP(Max [email protected]) Dual display:

29303136
373839

VESA Mount costs extra USD5, Please click the picture to pay together if you need:
