Four Lan Mini PC celeron 3215/core i3 4005U/core i5 4200U/core i5 5200U VPN Router appliance,Fanless Pfsense box

Four Lan Mini PC celeron 3215/core i3 4005U/core i5 4200U/core i5 5200U VPN Router appliance,Fanless Pfsense box
  • Продавецwww.arizonacardinalsvsdetroitlions.us
  • Список ценUS $130.00piece
  • Продажная ценаUS $130.00piece
  • ДоставкаБесплатная доставка
  • Рейтинги3,5 (147)

Oписание продукта

NC960NC250NC240NC290



i3 i5 Fanless Mini Computer
Intel i3 7100U/i5 7200U Dual Core , 3M Cache, TDP 15W,
DDR3 RAM, MSATA SSD ,WiFi, 4*USB 3.0, 1*VGA, 1*HDMI,
 Intel HD Graphics 620, [email protected], Fanless, Metal Case

01

Kindly Remind:
1, This computer works with lower voltage at 1.35V instead of normal 1.5V RAM.
2, its warranty is 3 years, for details, please read "Questions and Answers" below.
3, The RAM and SSD/HDD are from famous brand, the RAM is normally Samsung, Elpida, Hynix; The SSD is normally from Toshiba, Samsung, ADATA, Intel, Lite-on etc. they will be shipped out at random in stock.
4, The default Operating System Windows 10 Pro, it is just for testing, copied and activated but not licensed, please install the licensed one if you like it.
5, According to Aliexpress policy, it is buyer\'s duty to pay import tax; it is normally declared at USD105-120 to save buyer\'s tax, but not sure if it is free tax.
HTB1AbhKLXXXXXXuXFXXq6xXFXXXi

Product Advantages:
1. Special: 64 bits computing,  Hyper-Threading technology, Virtualization technology;
Support Wake-On-Lan; Support calls on function automatically;
Support SSD and HDD together, up to 512G SSD and 1TB Hardisk large volume;
Support Max 16GB DDR3 RAM, 2 RAM Slot; I/O port: 1 VGA, 1 HDMI, 1 LAN, 4 USB*3.0, 4*USB2.0
2. Stable: Intel Kaby Lake-ULT +Intel HD Graphics 620+Fanless
3. Smart: Fanless system, smart design, no noise, be able to work 24hours per day
4. Slim: Only 4cm body thickness, brushed black alloy case
5. Smooth: Support 3D games, blue-ray and HDMI 4K HD streams, full 1080P playback
6. Strong: Work for multiple application. For example: integrated with touch devices, industries, car repair shops, security, education, home as HTPC, business, fanancial and projector, Hotel.

04-7200U07-7200U0608091024121413

Product Specifications:


Processor

Intel® Core™ i3 7100U/i5 7200U Processor

Dual Core Quad Threads

Base Frequency 2.4GHz

Base Frequency 2.5GHz, Turbo Boost to 3.1GHz

14nmLithography

Intel Kaby Lake SOC Chipset

3MB L3 Cache

15W TDP

Instruction Set 64-bit

Multimedia Instruction Set

MMX, SSE, SSE2, SSE3, SSE4.1, SSE4.2, AVX

BIOS

AMI BIOS, ACPI supported

RAM

LPDDR3-1866, DDR3L-1600;

2gb/4gb/6gb/8gb/16gb optional, 2*SDRAM Slot

Storage

SSD: 32GB/64GB/128GB/256GB/512GB;

HDD: 250GB/320GB/500GB/640GB/1TB

Operating System

Default: Windows 10 Pro; Optional:Linux Ubuntu

Processor Graphics

Intel® HD Graphics 620

Graphics Base Frequency 300 MHz

Graphics Burst Frequency 1 GHz

Max Resolution (HDMI 1.4): [email protected]

Audio Card

ALC892 sound chip, 6-channel

Network Card

RTL 8111E 10/100/1000 BaseT LAN

Wireless

Wifi 802.11.b/g/n(150M or 300M), Dual Antennas; Bluetooth 4.0 optional

I/O Port

1*HDMI, 1*VGA, 1*RJ45 LAN Port, 4*USB3.0, 4*USB2.0,  1*DC IN, 1*MIC, 1*SPK

SATA

1*MSATA3.0 Slot, 6Gb/s; 1*SATA3 Connector, 6Gb/s

MINI PCIE

1* MINI PCIE Slot for Wifi Module

Power

In: DC100-240V AC/50-60Hz Out: DC 12V/3A

Operating Temperature

0°C~70°C (32°F~140°F)

Storage Temperature

-20°C~80°C (-68°F~176°F)

Relative Humidity

10%~90% (non-condensing)

Size

197mmx 197mmx39mm

Weight

1.5~1.65kg

Package Content

Mini PC, Power adapter, Power Cable, Wifi Antennas, Stand Bracket, Screws


Application
- used as HTPC(Home Theater Personal Computer). Connect HDTV with the HDMI cable, you can enjoy education online and play internet movies or games.
-used as Personal Computer, high configuration and fast speed, zero noise.
- Internet Bar. High speed Gigabit Ethernet and diskless certificate, support 3D games.
- Factory, classroom, bank, supermarket, manager rooms, stores.
- used in Library, reading room, hotel, training, call center, CCTV company.

202122232526

Product photos
2930323433373839

VESA Mount costs extra USD5, Please click the picture to pay together if you need:
